Detailed introduction to hydraulic height adjustment plate
Hydraulic height adjustment plate is a platform or pad driven by a hydraulic system and used for precise height adjustment. It is widely used in industries, logistics, automobiles, stage equipment and other fields. Its core principle is to use hydraulic cylinders or hydraulic pumps to provide power to achieve a stable and efficient lifting function.

1. Structure and working principle of hydraulic height adjustment plate
(1)Main components
①Hydraulic oil cylinder: core power component that pushes the piston movement through hydraulic oil pressure.

②Hydraulic pump/power unit: Provides hydraulic oil pressure, which can be a manual pump, an electric pump or a pneumatic pump.

③Control valve: Adjust the hydraulic oil flow direction, control the lifting speed and locking position.

④Load-bearing platform: Usually made of high-strength steel or aluminum alloy to support the load.

⑤Safety devices: such as explosion-proof valves, mechanical locking mechanisms to prevent accidental drops.

(2)How it works
①Ascending process: The hydraulic pump supplies oil to the oil cylinder, pushes the piston rod to extend, and raises the platform.

②Descent process: The control valve slowly releases hydraulic oil, and the platform drops steadily under load or gravity.

③Locking mechanism: Keep the height stable through a check valve or mechanical locking device.

2. Advantages of hydraulic height adjustment plate
(1)High load capacity
The hydraulic system can provide great thrust and is suitable for height adjustment of heavy equipment (such as machine tools, cars, containers), and can bear dozens of tons of load.

(2)Smooth and accurate control
The hydraulic transmission has no impact and stable lifting process, which is suitable for precision equipment adjustment (such as semiconductor manufacturing, optical instrument calibration).

Available in millimeter-level fine adjustment, which is better than mechanical spiral or pneumatic adjustment methods.

(3)Adjust height across a large range
The travel range is wide, from a few centimeters to several meters to custom-made (such as stage lifts, car lifts).

(4)Safe and reliable
The hydraulic system comes with a self-locking function, which can keep the position unchanged even if the power is cut off or oil leakage.

Equipped with explosion-proof valve and overload protection to prevent accidental falls.

(5)Adapt to harsh environments
The hydraulic system is resistant to high temperature, dust and vibration, and is suitable for complex working conditions such as factories, mines, outdoors and other conditions.

(6)Low maintenance requirements
Compared with pneumatic systems (needed to air compressors) or electric systems (easy to wear), hydraulic systems are simple to maintain, and only regular inspection of oil circuits and seals are required.

(7)Energy-saving and efficient
Energy is consumed only when lifting and lowering, and no power consumption is required when stationary (the electric system needs to be continuously powered and maintained at the position).

3. Typical application scenarios
(1)Industrial manufacturing: machine tool installation, production line height adjustment, mold replacement.

(2)Logistics and warehousing: truck platform adjustment, forklift loading and unloading platform.

(3)Automobile repair: hydraulic lift, four-column lifting platform.

(4)Stage performance: can be adjusted by lifting and lighting equipment.

(5)Military/Aviation: Missile loading, aircraft maintenance platform.

(6)Medical equipment: height adjustment of operating table and imaging diagnostic instrument.

Product Specifications Table
